With internal control and external control oftwo control modes, external control mode can be through 485 communication mode power control.
Compact size, high power output, and precise output voltage accuracy.
Fast charging speed (charging time < 40ms from 0-1000V for a 100uF capacitor).
Open circuit, short circuit, arc, over-temperature, and over-voltage protection.
The medical aesthetic power supply comes standard with a protective casing, reinforced filtering circuits, and meets EMC certification standards.
This product complies with YY0505-2012 or IEC60601-1-2 standards for medical electrical equipment.
Adopting high-frequency resonance technology to achieve efficient and small volume design, power closed-loop control ensures stable arc, and high-altitude load voltage improves ignition success rate.
Multiple protection mechanisms (overvoltage/short circuit/overload), combined with modular circuit design, ensure reliable operation and easy maintenance.
Supports 0-5V power regulation, TTL switch, and RS232 interface, and can be remotely controlled by a computer to meet diverse application needs.
| Model | LCP1012 | LCP700 |
|---|---|---|
| Input Voltage | AC220V±15%,47-63Hz | |
| Leak | <0.4mA AC250V | |
| Output Voltage | MaxDC 0-1000V | MaxDC 0-700V |
| Output voltage stabilization accuracy | ±0.1% | |
| Output Power | 1200W | 1000W |
| Control Method | analog quantity | RS485 |
| Cooling Method | air cooling | |
| Dimensions（mm） | 470*200*150 | 146*205*88 |
| Weight（KG） | 6 | 3 |
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
