Easy remote/automatic conversion: The device is equipped with intuitive remote/automatic conversion functions, and users only need to use the accompanying jumper to easily switch between the two modes seamlessly, making the operation simple and fast.
Flexible current regulation: The device supports free adjustment within a wide current range (7-16A/175W and 11-25A/300W) to meet the current requirements of different application scenarios and achieve more flexible control.
Multiple security guarantees: The device is equipped with comprehensive protection mechanisms, including short-circuit protection, overheating protection, and overload protection, effectively improving the reliability and safety of the power supply, ensuring stable operation of the device under various harsh conditions.
Integrated and convenient design: The constant current and trigger modules adopt an integrated design, and the output port is directly connected to the xenon lamp without additional wiring, simplifying the operation process and improving the convenience of use.
Constant current output mode: The device adopts a constant current output mode with power limitation to ensure stable output current and effectively prevent equipment damage caused by excessive power, thereby improving device durability.
Global Voltage Adaptation and Stability: Advanced Active Power Factor Correction (PFC) technology is adopted to effectively reduce harmonic interference at the input end, increase power factor, and enable equipment to easily adapt to global grid voltages, improving equipment compatibility and stability.
Supports wide range current regulation of 7-16A (175W) and 11-25A (300W) to meet different application requirements, with more precise and flexible control.
Remote/automatic mode one click jumper switching, simple and efficient operation, meeting the diverse application needs.
Active PFC technology for global voltage adaptation, multiple protection mechanisms+integrated design, ensuring high reliability and durability of equipment.
| Specifications | HCX0175-S | HCX0300-S |
|---|---|---|
| Input Voltage | AC88V-AC265V，50Hz/60Hz | |
| Input power factor | >0.90 | |
| Input cold surge current | ≤ 42A (AC230V input), ≤ 20A (AC115V input) | |
| Input leakage current | ≤ 0.3mA (AC230V input), ≤ 0.15mA (AC115V input) | |
| Maximum Output Current (A) | 16 | 25 |
| Rated output current (A)* | 14 | 21 |
| Adapt to Xenon Lamp Work Voltage (V) | 12.5 | 14 |
| Current Ripple | lpp ≤ 1% | |
| Stability (half an hour after startup) | ≤±0.5% | |
| Auxiliary output | 12VDC+2% 1A | |
| Remote/automatic control | Remote: Use an external switch to control the power on and off; Automatic: The power supply starts automatically after connecting to the current source | |
| Efficiency | ≥80%（at full load） | |
| Mean Time Between Failures | ≥50000H | |
| Turn-on delay | ≤1s | |
| Voltage Resistant | input chassis：AC1500V 5mA 60s | |
| Protection Function | Output short circuit protection, overload protection, and over temperature protection | |
| Operating | Temperature：0-50°C, Relative Humidity：≤90% | |
| StoreTemperature | （-20-+85）℃ | |
| Cooling Method | forced air cooling/200-400LFM | |
| PCB board size (mm) | 117*114*80 | |
| Weight (KG) | 0.8 | |
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
