Multiple fault detection and troubleshooting can be easily handled;
Including amplifier power supply, seed source drive power supply, TEC cooling control, laser shutter drive, power control system;
The amplification voltage is adjustable, and the driving current of the seed source LD is precisely adjustable;
Unique and rich parameter settings and storage functions;
Medical beauty power supply comes standard with a protective casing, which is radiation resistant, anti bounce, and has a stable installation structure;
The whole machine is designed in accordance with the YY0505-2012 and IEC60601-1-2 standards for medical electrical equipment.
Integrated amplifier power supply, seed source driver, TEC cooling and optical gate driver, adjustable and storable parameters, intelligent and convenient operation.
Compliant with YY0505/IEC60601 standards, with anti radiation and anti bounce design, ensuring treatment safety and equipment stability.
The amplification level voltage and seed source current are accurately adjustable, and fault detection responds quickly, ensuring efficient and stable output of genuine leather laser in seconds.
| Specifications | Parameter |
|---|---|
| Seed source LD driver parameter | |
| LD Output Voltage | adaptive |
| LD Output Current | 2-20A |
| Discharge Pulse Width | 30-800us adjustable |
| Output Frequency | 1-10Hz adjustable |
| Current Regulation Step Size | 0.1A |
| Current Rising Ddge And Falling Edge | < 10μs |
| Current Output Accuracy | ≤ ±1%lo |
| Current Ripple | ≤ ±0.5%lo |
| Protection Signal | Over temperature protection, over-current protection, short circuit and open circuit protection |
| YAG amplification level parameter | |
| Input Voltage | AC220V±15%,47-63Hz |
| Leakage Current | <0.4mA AC250V |
| Output Voltage | DC300-1300V |
| Output Power | 1000W |
| Output Frequency | Max10Hz |
| Weight（KG） | 12.5 |
| Dimensions（mm） | 400*300*200 |
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
