Integrated design: including pre burning laser power supply, control system, and capacitor;
Powerful supporting software: human-machine interaction operation screen (customizable)+adjustable backend voltage parameters;
Unique high current plug and unplug device, easy to install and disassemble, saving labor costs;
Adopting new technology and modular design to ensure efficiency, stability, and anti-interference;
Fault problem location, including over temperature, water flow, pre combustion, and charging alarm prompts;
Patent design can ensure high consistency of continuous pulse output energy;
Medical beauty power supply comes standard with a protective casing, which is radiation resistant, anti bounce, and has a stable installation structure;
The whole machine is designed in accordance with the YY0505-2012 and IEC60601-1-2 standards for medical electrical equipment.
Pre combustion power supply+control+capacitor three in one design, matched with customizable software, flexible parameter adjustment, intuitive and convenient operation.
Patent technology ensures pulse energy consistency, modular anti-interference design, and high current plug to improve maintenance efficiency.
Compliant with YY0505/IEC60601 standards, equipped with intelligent fault alarm and radiation resistant casing, ensuring safe and reliable treatment.
| Power Parameters | |||
| ModelSpecifications | QPM500 | QPM2000 | |
| Input Parameters | Input Voltage | AC220V±15%，47 - 63Hz AC110V±15%，47 - 63Hz | AC220V±15%，47 - 63Hz/110V |
| Leakage Current | < 0.4mA/250AC | < 0.4mA/250AC | |
| Output Parameters | Output Power | 500W | 2000W |
Maximum output energy per pulse (Under the condition of a capacitance of 100 μ F) | 50J | 200J | |
| Output Frequency | 1 - 10Hz | Single time,1HZ-5HZ | |
| Electric pulse width | <150μs | <450μs | |
| Touch Screen | 4.3h、8h、10.4h | ||
| Temperature | Work：-15℃ - 45℃ Storage：-40℃ - 85℃ | ||
| Humidity | No frost or condensation | ||
| Safety regulations and electromagnetic compatibility | Designed in accordance with YY0505-2012 and IEC60601-1-2 standards for medical electrical equipment | ||
| Cooling Method | forced air cooling | ||
| Dimensions (mm) | 270*124*124 | 315*200*135 | |
| Weight (KG) | 3.1 | 4.9 | |
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
