Input range: AC342V-456V, 50/60Hz;
4-channel * 50A constant current output, each output can be enabled separately and the output current can be set separately;
The fastest rising edge of the driving current can reach 10us, with no overshoot or kickback;
Output pulse operating frequency 0-10KHz;
Output current ripple: not exceeding 1%; Current stability: ± 0.5%;
MOPA structure, strict start stop sequential automatic control of each current;
Hardware interlocking protection for optical power exceeding limit, overcurrent, overtemperature, etc., with fast response speed;
High speed and precise power adjustment tube thermal management function ensures the safety of power tube operation;
Multiple remote controls;
Real time detection and control of multi-channel laser power PD, temperature, humidity, flow rate, etc;
Working parameters, interlock protection values, alarm values, calibration PD, etc. can be set through the upper computer;
Run time encryption settings;
Waterproof and dustproof grade IP55 structural design.
Note 1: The length of the line from the driver output to the laser module cannot exceed 1m; /p>
4 independent 50A constant current outputs, each can be individually controlled, with a current stability of ± 0.5%, ripple not exceeding 1%, and a fast response of 10us without overshoot, meeting the requirements of precision machining.
MOPA timing control+hardware interlock protection (overcurrent/overtemperature, etc.), combined with intelligent thermal management, IP55 protection level, ensures stable and safe operation under high power of 6kW.
Support setting working parameters/interlock protection values on the upper computer, as well as setting protection alarm values and calibration, with operation encryption function, to achieve industrial grade intelligent control.
| Specifications | Parameter |
|---|---|
| Input Voltage Scope | AC342V-456V, 50/60Hz |
| Output Voltage | Optional according to customer needs 80V/100V/120V |
| Output Parameters | Each output of 1-50A can be set |
| Current rising/falling edge | ≤ 10uS， No overshoot, no recoil injection 1 |
| Output current quality | Current ripple: not exceeding 1%; Current stability: ± 0.5%; |
| Whole machine output power | ≮ 20kW |
| Overall Efficiency | ≥90% |
| Communication interface | Communication method: Ehernet connect CAN, RES485 |
| Control mode | Debugging mode, Work mode |
| Temperature | Temperature：-25-60℃；StorageTemperature：-40-85℃ |
| Insulation | Voltage Resistant： 1500Vac 10mA 60S，Insulation resistor≥ 10MΩ |
| Protection level | IP55 |
| Dimensions | 475mm*410mm*65mm |
| Weight | 10kg |
| Cooling Method | water cooling |
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
