By using an optical power meter, optical power feedback can be achieved, allowing for precise control of laser output power;
Built in laser power supply, mirror power supply, water pump power supply, red light drive, air pump, water pump control;
Intelligent start stop of air pump and water pump, reducing noise and improving the service life of air pump and water pump;
Better coordination and stronger functionality with the dedicated control system of radium source (to be purchased separately);
Can support continuous, single, pulse and other working modes, with super practicality;
Equipped with open circuit protection function, it can automatically cut off power protection when the high voltage end is open or not connected to the power supply, which can effectively increase the safety of beauty equipment and prolong the service life of the power supply;
Medical beauty power supply comes standard with a protective casing, which is radiation resistant, anti bounce, and has a stable installation structure;
This product complies with the YY0505-2012 or IEC60601-1-2 standards for medical electrical equipment.
Real time feedback of optical power, supporting continuous/single/pulse multi-mode output, precise adjustment of treatment parameters, meeting diverse clinical needs.
Integrating laser, galvanometer, water pump, and air pump drive, intelligent start stop reduces energy consumption and noise, and extends the service life of core components.
High voltage open circuit automatic protection+anti radiation and anti vibration casing, in compliance with medical safety standards, ensuring the safety and reliability of the treatment process.
| 电源Model | LMESC | LMESC-S | |||
|---|---|---|---|---|---|
| Input Parameters | Input Voltage | 110V/220V±15%, 47-63Hz optional | AC90-260V, 47-63Hz | ||
| Communication Frequency | 47-440Hz | 47-440Hz | |||
| Maximum Input Power | 400W | 400W | |||
| Maximum Input Current (90V时) | 4A | 5A | |||
| Output Parameters | Maximum Output Voltage | 25KV | 20KV | Auxiliary power supply voltage | 24V, -24V, 15V, -15V, 5V |
| Maximum Output Current | 20mA | 20mA | Auxiliary power supply current | 3A, 0.5A, 1A, 0.5A, 2A | |
| Efficiency | ≥ 90%（at full load） | ||||
| Mean Time Between Failures | ≥ 10000h | ||||
| Switch Mode | TTL level | Serial port protocol, LCD screen, TTL level | |||
| Cooling Method | forced air cooling | ||||
| Operating | Temperature: -10~40°C Relative Humidity: ≤ 90% | ||||
| Dimensions (mm) | 176×169×97 | 320×97×95 | |||
| Weight (KG) | 1.4 | 2.1 | |||
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
