Route 6& amp; 4-channel * 30A independent constant current output, each output current software can be adjusted and enabled separately;
It can be expanded to 250 * 6 through the main control board; amp; 25 * 4=100 constant current outputs, with synchronization errors of no more than 1uS for each channel during switching; /p>
Adaptive output voltage of 20-180V (maximum constant current decreases with increasing output voltage);
The maximum power per channel can reach 2KW;<; p="">
The rising and falling edges of the output current are less than 10us; there is no overshoot or kickback;
Output current ripple less than ± 0.2%; The comprehensive adjustment rate of current is less than ± 0.5%;
It can set working parameters, interlock protection values, alarm values, calibrate PD, etc; Can record running time, store 24 sets of running parameters for direct calling, store fault record analysis and upload;
Combined with a dedicated main control board, multiple control modes can be achieved, including local control, remote RS485 control, and remote analog control;
Overtemperature, overcurrent hardware, software interlock protection, PD hardware interlock protection ensure the safety of the rear laser;
Input voltage detection, undervoltage and overvoltage alarm;
High speed and precise power adjustment tube thermal management function ensures the safety of power tube operation;
Real time detection and control of multi-channel laser power PD, temperature, humidity, flow switch, etc;
Comes with indicator light drive and control.
6/4-channel independent 30A constant current output, single channel power up to 2KW, synchronization error ≤ 1 μ S, current ripple<± 0.2%, 10 μ s fast response without overshoot.
Supports synchronous output from multiple devices (error<1 μ s), with multiple hardware and software protections, touch screen human-machine interaction, and flexible and convenient parameter settings.
Hardware overcurrent/short circuit protection+software over temperature/overvoltage protection, real-time monitoring of chassis status indicator lights to ensure high reliability operation.
| Model | LDM4000-4 | LDM6000-6 |
|---|---|---|
| Input Voltage | LD voltage + (2.5-3.5)V | |
| 4 | 6 | |
| Output Voltage | First line: 2-24V, other lines, 50-180V | |
| Output current | 4 * 0-30A constant current adjustable | 6*0-30A constant current adjustable |
| Output Voltage quality | Current ripple: ± 0.2%; The comprehensive adjustment rate of current is less than ± 0.5%; | |
| Current rising/falling edge | <10uS，No overshoot, no recoil | |
| Maximum output power of the whole machine | Not less than 8KW | Not less than 12KW |
| Start-stop Control | Strict start stop sequential automatic control of various currents | |
| Protection | Over temperature, over current hardware, software chain protection, PD hardware chain protection | |
| Chain protection | Current and PD interlock protection, hardware interlock protection for startup sequence | |
| Warmth Humidity | Work: -25-60 ℃, 20-90% RH, no condensation; | |
| Safety regulations and electromagnetic compatibility | Complies with relevant industry standards | |
| Volume | 186mm*105mm*43mm | 275mm*105mm*43mm |
| Weight | 0.9kg | 1kg |
| Cooling Method | water cooling | |
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
