Intelligent upgrade: Built in computer control, can communicate with motion control board, and through cascading, can achieve communication with up to 32 power supplies. Real time display of power related parameters on the laser machine panel enables complete machine upgrade. Facilitating user monitoring, improving user experience, and increasing the selling points of laser machine products.
Multi functional LCD display (optional): One LCD display can simultaneously display information for two laser power sources, or display information for one laser source. The display screen automatically switches, making it convenient for multiple laser head machines to use. At the same time, the monitor can be connected to the board and display power information on the LCD monitor.
Stronger universality: Active PFC function, AC90-264V ultra wide input voltage range, globally applicable, no need to worry about input voltage mismatch.
Open circuit protection function: The open circuit protection function automatically protects the high-voltage end from open circuit or power failure, effectively preventing high-voltage ignition and increasing the safety and reliability of the entire laser machine.
Higher safety: Equipped with high-voltage discharge function, there is no residual high voltage after shutdown, making it safer.
Supports 32 power level communication devices, managed through motion control boards, and real-time monitoring of laser machine panel parameters to enhance the overall intelligence and user experience of the machine.
Active PFC supports AC90-264V global voltage, with open circuit protection and automatic high-voltage discharge function, eliminating the risk of high-voltage ignition and ensuring safe and reliable use.
An optional LCD screen can display dual power data simultaneously, with automatic screen switching and perfect compatibility with multiple laser head devices, making information display more intuitive and convenient.
| Model | Z80 | Z100 | Z150 |
|---|---|---|---|
| Input Voltage | AC90-264V | ||
| Communication Frequency | 47-63Hz | ||
| Maximum Input Power | 600W | 650W | 900W |
| Maximum Input Current | 5.5A | 6A | 8A |
| Maximum Output Voltage | 40KV | 45KV | 55KV |
| Maximum Output Current | 28mA | 32mA | 38mA |
| Efficiency | ≥ 90% (at full load) | ||
| Mean Time Between Failures | ≥ 10,000hour | ||
| Response Speed | ≤1ms（The time from the switch signal to the output current rising to 90% of the set current） | ||
| Switch Control Mode | TTL level | ||
| Power Control Mode | PWM (above 20KHz) or 0-5V or 0-3.3V analog quantity | ||
| Communication Method | Special serial port mode | ||
| Voltage Resistant | Input output, input chassis: AC1500V 10mA 60s | ||
| Operating | Temperature：-10-40℃ Relative Humidity：≤ 90% | ||
| Cooling Method | forced air cooling | ||
| Matching Laser Tube Power | 50-80W | 90-120W | 120-180W |
| Dimensions (mm) L×W×H | 235×144×104 | 278×144×104 | 330×144×104 |
| Case Color | silver gray | ||
| Weight (KG) | 2.15 | 2.45 | 3.2 |
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
