High speed response: With a response time of less than 10us, it can quickly detect changes in optical signals;
Good output characteristics: there is a good linear correspondence between the output voltage and the input optical power;
Wide detection range and good adaptability: The detection wavelength range is 400nm-1200nm, and it is most sensitive to wavelengths around 940nm, with a certain decrease in sensitivity to light photography in other ranges.
Fast detection time of less than 10 μ s, real-time capture of transient changes in optical signals, meeting the requirements of high-speed applications.
The output voltage maintains a highly linear relationship with the input optical power to ensure the accuracy and reliability of the detection data.
Wide wavelength detection range of 400-1200nm, sensitive to 940nm peak, compatible with multiple light source scenarios.
| Specifications | Min | Typical | Max | Unit |
|---|---|---|---|---|
| Wavelength detection Scope | 400 | 940 | 1200 | nm |
| Supply Time | -- | -- | 10 | μs |
| Supply Voltage | 4.5 | 5.0 | 5.5 | V |
| Output Voltage | 0 | -- | 4 | V |
| Output Capability | -- | -- | 5 | mA |
| Temperature | Temperature：-25-60℃；StorageTemperature：-40-85℃ | |||
| Humidity | Work：20-90%RH， Non condensing Storage: 10-95% RH, non condensing | |||
| Volume | 38mm*33mm*7mm | |||
Warranty: 360 days
▶ The warranty period for power products is 12 months, calculated from the date of purchase.
▶ During the warranty period, faults that are not caused by human factors can be repaired free of charge; Malfunctions caused by human damage or excessive use require paid repairs.
▶ Before using this power supply, please read the manual carefully. We are not responsible for any damage or problems caused by improper use or failure to follow the manual
